Argox CP-3140L
Intermediate Level Barcode Printer



● Direct Thermal And Thermal Printing
● 203 DPI Printing Resolution
● Max. 104 mm Printing Width
● Max. 1270 mm Printing Length
● Max. 102 mm / Sec Printing Speed
● 8 MB DRAM and 4 MB Flash ROM
● PPLA and PPLB Support
● A variety of paper sensor system for diverse applications
● Ribbon wound ink-side out or ink-side in available
● Four Auto-Calibration Modes
● Printing noise improved
● LPT, RS-232C and USB Port

 Operational
 Printing method Direct thermal and thermal transfer
 Printing resolution 203 DPI (8 dots/mm)
 Printing speed (Maximum) 102 mm/saniye
 Printing length 13 ~ 1270 mm
 Printing width 25 mm ~ 104 mm
 Memory 8 MB DRAM and 4 MB Flash ROM
 Proccessor 32 Bit RISC proccessor
 Operation interface 1 button (Feed) and 2 LED (Power and Ready)
 Communication interface LPT, RS-232 and USB Port
 Sensor Reflective media sensor (Movable)
Transmissive media sensor (Fixed and Center)
Head open switch sensor
Ribbon end sensor
 Print directions 0, 90, 180, 270 degree
 Agency listing CE, FCC, cTUVus, CCC, RoHS
 Physical
 Width 225 mm
 Height 186 mm
 Length (Depth) 273 mm
 Weight 2,1 kg
 Material ABS Plastic
 Electrical
 Power input type External adaptor
 Power source (Input) 100V~240V±10%, 1.5A, 50~60Hz
 Power source (Output) 24VDC,2.91A (Typical) 70W Max.
 Environmental
 Operation temperature 4 °C ~ 38 °C
 Storage temperature -20 °C ~ 50 °C
 Humidty %10 ~ %90 (Non Condensing)
 Label
 Type Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper
 Width 25,4 mm ~ 110 mm
 Thickness 0.0635 ~ 0.254 mm
 Roll Inside diameter 25,4 mm
 Roll Outside diameter 127 mm (Maximum)
 Ribbon
 Type Wax, Wax/Resin and Resin
 Ink side Outside
 Width 25,4 mm ~ 110
 Length 300 Meter (Maximum)
 Roll Inside diameter 25,4 mm
 Roll Outside diameter 67 mm (Maximum)
 Software
 Windows drivers Windows XP / Vista / 7 / 8 / 8.1, Windows Server 2003 / 2008 / 2012
 Label Design programs Bartender UltraLite (Free)
 Utility programs Printer Utility and Font Utility
 Supported barcode printing language PPLA, PPLB
 Supported graphics formats PPLA: PCX, BMP, IMG and HEX
PPLB: PCX, BMP,  GDI and Binary Raster
 Supported Barcode Types
 1D

PPLA: Code 39 (standard/with checksum digit), Code 93 Interleaved 2of 5 (standard/with checksum digit/with human readable check digit), EAN-8, EAN-13,UPC-A, UPC-E, Postnet, Codabar, Code 128 subset A/B/C, UCC/EAN-128, UCC/EAN-128 K-MART, UCC/EAN-128 , Random Weight, Plessey, HBIC, Telepen, FIM, UPC2, UPC5, GS1 Data Bar
PPLB: Code 39 (standard/with checksum digit),Code 93 Interleaved 2 of 5 (standard/with checksum digit/with human readable check digit), EAN-8 (standard/2 digit add-on/5 digit add-on), EAN-13 (standard/2 digit add-on/5 digit add-on), UPC-A (standard/2 digit add-on/5digit add-on), UPC-E (standard/2 digit add-on/5 digit add-on), Postnet, Codabar, Code 128 subset A/B/C, Code 128 UCC (Shipping Container Code), Code 128 Auto, German, Postcode, Matrix 2 of 5, UCC/EAN 128, UPC Interleaved 2 of 5, GS1 Data Bar

 2D PPLA/PPLB: MaxiCode, PDF417, Data Matrix (ECC200 Only), QR code, Composite codes
 Accessories
 Optional Items Cutter
RTC Card
ArgoKee
