Operational |
|
Printing method |
Direct thermal |
|
Printing resolution |
203 DPI (8 dots/mm) |
|
Printing speed |
Max. 127 mm/sec (With Liner) |
|
Max. 102 mm/sec (With Linerless) |
|
Printing width |
Max. 72 mm |
|
Memory |
128 MB DRAM, 256 MB Flash ROM |
|
Sensors |
Media Gap |
|
Black Mark |
|
Paper cover open |
|
Communication
interface |
Serial, USB and Bluetooth |
|
NFC |
For Easy Bluetooth Pairing |
|
Physical |
|
Width |
105 mm |
|
Height |
58 mm |
|
Depth |
126 mm |
|
Weight |
385 gr (Including Battery) |
|
13 gr (Only Paper) |
|
Electrical |
|
Battery |
7.4V Li-ion, 2600 mAh |
|
Charging Time |
Up To 4 hours |
|
Environmental |
|
Operation temperature |
-15°C ~ 50°C |
|
Storage temperature |
-30°C ~ 70°C |
|
Humidty |
%10 ~ %80 (Non Condensing) |
|
Sealing |
IP54 |
|
Drop Rate |
1.8 meter |
|
Paper |
|
Type |
Label |
|
Width |
Max. 72 mm |
|
Thickness |
0.07 mm ~ 0.15 mm |
|
Roll Inside diameter |
Min: 19 mm |
|
Roll Outside diameter |
49 mm (Maximum) |
|
Supply Method |
Easy Paper Loading |
|
Software |
|
Emulation |
SLCS, BPL-Z, BPL-C |
|
Driver |
Windows (Europlus, Seagull), Linux, MAC ve Virtual Com USB Driver, OPOS/JPOS, SAP Device Driver |
|
Tools |
Utility program |
|
Programs |
Label Artist Mobile (Android, iOS), mPrint App (Android, iOS) |
|
SDK / Plugin |
iOS SDK, Android SDK, Windows SDK, Linux SDK, Chrome SDK |
|
Applications |
Label Artist™ Mobile (Android, iOS), mPrint App (iOS), mPrint Server (Windows, iOS) |
|
Fonts |
10 SLCS / One SLCS / 16 BPL-Z™ / One BPL-Z™ / 7 BPL-C™ / 23 Code Page / Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
|
Graphics |
Supporting user-defined fonts, graphics, formats, layouts, and logos |
|
Supported Barcode Types |
|
1D |
Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC / EAN extensions, UPC-A, UPC-E, IMB |
|
2D |
Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code,TLC 39 |
|
Accessories |
|
Standart Items |
Belt Clip, Battery Pack, Battery Charger, Power Cord |
