Technical
Features |
|
|
Printing method |
Direct thermal /Thermal transfer |
|
Printing Resolution |
203 DPI (8 dots/mm) |
|
Printing speed |
Up to 4 ips (100 mm/sec) |
|
Printing
Length |
4 ~ 1727 mm |
|
Printing Width |
25 ~ 108 mm |
|
Memory |
4MB Flash ROM (2 MB user storage),
8 MB DRAM |
|
Proccessor |
32 bit RISC microprocessor |
|
Operation
Interface |
One Tri-color
LED: Power (Green, Orange and
Red)
Function Key: FEED |
|
Communication Interface |
USB(2.0) |
|
Media
Sensor |
Reflective / Transmissive (fixed) |
|
Dimensions |
Width:224 mm, Heigth:170 mm, Length:254
mm |
|
Weight |
2,5 kg |
|
Power Source
(Input) |
110V~220V±10%, 50~60Hz |
|
Agency
Listing |
CE(EMC), FCC
Class A, CB, CCC |
|
Operation
Temperature |
5 °C ~ 40 °C |
|
Storage
Temperature |
-20 °C ~ 50 °C |
|
Operation
Humidity |
%30 ~ %85 (non-condensing) |
|
Storage
Humidity |
%10 ~ %90
(non-condensing) |
|
Printing directions |
90, 180, 270 degree |
|
Optional Items |
İnternal RS-232 card,
Ethernet 10/100Mbps print server
(default off; disables USB when
in use)
External label roll holder for
10” (250 mm) O.D. label rolls
External label rewinder |
|
Software
Features |
|
|
Windows Drivers |
Windows 2000/XP/2003/VISTA/Windows
7 |
|
Label design software |
Label design software:
QLabel-IV (for EZPL only) |
|
Emulations |
EZPL, GEPL (Godex
Eltron® Printer Language), GZPL (Godex Zebra® Printer Language) |
|
Supported Barcodes Types |
1D Barcode :
Code 39,
Code 93, Code 128 (subset A, B,
C), UCC/EAN-128 K-Mart, UCC/EAN-128,
UPC A / E (add on 2 & 5), I 2 of
5, I 2 of 5 with Shipping Bearer
Bars, EAN 8 / 13 (add on 2 & 5),
Codabar, Post NET, EAN 128, DUN
14, HIBC, MSI (1 Mod 10), Random
Weight, Telepen, FIM, China
Postal Code, RPS 128 and GS1
Databar
2D Barcode :
PDF417,
Datamatrix code, MaxiCode, QR
code and Micro QR Code |
|
Resident
Fonts |
Bitmap fonts 6, 8, 10,
12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°,
270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable |
|
Download
Fonts |
Bitmap fonts 90°, 180°,
270° rotatable, single characters 90°, 180°, 270° rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in
horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable |
|
Code Pages |
CODEPAGE 437, 850, 851,
852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255
Unicode (UTF8, UTF16) |
|
Supported Graphics Types |
Resident graphic file
types are BMP and PCX, other graphic formats are downloadable from the
software |
|
Media
(Paper) Features |
|
|
Type |
Roll-feed, die-cut, continuous,
fan-fold, tags, ticket in
thermal paper or plain paper and
fabric label |
|
Width |
25,4 mm ~ 118 mm |
|
Thickness |
0.06 ~ 0.2 mm |
|
Core size |
25,4 ~ 38,1 mm |
|
Roll
capacity |
127 mm (Max.) |
|
Ribbon
Features |
|
|
Type |
Wax , Wax/Resin , Resin |
|
Ink Side |
Outside |
|
Length |
110 meter (Max.) |
|
Width |
30 mm ~ 110 mm |
|
Core
size |
12,7 mm |
|
Roll
capacity |
40 mm (Max) |
|
|
