● Android 4.1.1 (Jelly Bean) operation systems
● TI OMAP 4470 Dual Core 1,5 Ghz proccessor
● 1 GB DDR-RAM, 8 GB eMMC ROM
● 4,7 Inch (1280 x 720 pixel) TFT, IPS LCD Display
● Wifi, Bluetooth, RFID, GPRS (3,5G), GSM, GPS technology
● 1,2 mt (4 ft) drop resistance
● IP65 Protection Class
● 5MP CMOS Sensor Autofocus Camera with Flash
| System | |
| Micro Processor | TI OMAP 4470 dual core 1,5 Ghz Micro Processor |
| Memory | 1 GB Mobile DDR RAM, 8 GB eMMC Flash ROM |
| Operation System | Android 4.1.1 (Jelly Bean) |
| Supported Language | English, Simp. Chinese, Traditional Chinese, Japanese, Spanish, German, French |
| Display | |
| Display Type | IPS LCD |
| Dimension | 4,7" (Inch) |
| Resolutioin | 1280 x 720 Pixel |
| Brightness | 450 Nits |
| Touch Panel | Gorilla Glass II with 5-point capacitive |
| Keypad | |
| Keypad | 4 function keys, 2 scan keys, volume keys, power keys |
| Indicator | |
| Types | 1 LED indicate charge/Message, Vibrator |
| Barcode Scanner | |
| Type | Standart: 1D CCD Barcode Scanner |
| Optional: 2D Imager Barcode Scanner | |
| Supported Barcode Types | UPC-A/E, EAN-8/13, Codabar, Code 39, Code 39 full ASCI, Code 93,Code 32, Interleaved & Std. 2 of 5, EAN 128, Code 11, Delta, MSI/Plessey,Code 128, Toshiba, RSS expended, RSS Limited, RSS14 |
| Audio | |
| Types | 1W Speaker 85 dB at 10 cm |
| 3.5mm Audio Jack | |
| Reciever | |
| Microphone | |
| Input Devices | |
| Types | Keypad |
| Touch Screen | |
| Full Alphanumeric Software Keyboard | |
| Barcode Scanner | |
| Camera | 5 Megapixel (With Flash) |
| Regulatory Approvals | |
| Regulatory Approvals | CE, NCC, FCC, BSMI, VCCI, CCC and RoHS compliance |
| Communication | |
| USB | USB 2.0 OTG |
| WLAN | 802.11 b/g/n |
| PAN | Bluetooth 4.0 |
| WWAN | GSM/GPRS/EDGE 850/900/1800/1900 MHz UMTS |
|
850/900/1700/1900/2100 MHz WCDMA
modem, HSPA+, DL: 21Mbps/ UL: 5.76Mbps |
|
| GPS | Yes |
| Other Sensors | eCompass |
| Light & Proximity sensor | |
| G-Sensor | |
| RFID Reader | |
| Frequency | 13.56 Mhz |
| Tag Support | ISO15693, ISO14443A , ISO14443B (NFC Supported) |
| Power | |
| Main Battery | 3,7V 3220 mAH Li-Polymer Battery |
| Backup Battery | 1 Hour capacity |
| Working time | ~ 11 Hours |
| Physical | |
| Weight | 285 gr (Battery Included) |
| Dimensions | Height: 160 mm, Thicness: 17,4 mm, Width:80 mm (Without Barcode Scanner) |
| Enviromental | |
| Operating temperature | -10°C to 50°C |
| Storage temperature | -20°C to 60°C |
| Charging temperature | 0°C to 40°C |
| Relative Humidity | %5 ~ %95 (Non-Condensing) |
| Drop test to Concrete | 1,2 meter |
| Environmental Sealing | IP65 |
| Vibration and Shock test | MIL-STD-810F, 514.4 process II |
| Software | |
| Software | Android 4.1.1 API level 16 |
| Accessories | |
| Accessories | Single Slot USB Client Cradle with Single Slot Battery Charge |
| Handstrap | |
| 3220 mAH Battery | |
| MicroUSB Cablo | |
| Power adaptor with universal plugs | |
