Operational |
|
Printing
method |
Direct thermal
and thermal transfer |
|
Printing
resolution |
203 DPI (8 dots/mm) |
|
Printing
speed (Maximum) |
152 mm/saniye |
|
Printing
length |
13 ~
7620 mm |
|
Printing
width |
25 mm ~ 168 mm |
|
Memory |
2 MB DRAM, 1 MB Flash ROM |
|
Proccessor |
32 bit RISC micro proccessor |
|
Operation
interface |
3 Button (Feed, Pause and Cancel) |
|
3 LED (Ready, Media and Ribon) |
|
Communication
interface |
Centronics Parallel and Serial
Port (RS-232C) port |
|
Display |
Back-lit LCD |
|
Sensor |
Reflective and transmissive
media sensor
(Movable) |
|
Ribbon end sensor |
|
Print
directions |
0, 90, 180, 270 degree |
|
Agency
listing |
CE,
FCC, UL, CUL, CCC, RoHS |
|
Physical |
|
Width |
310 mm |
|
Height |
260 mm |
|
Length (Depth) |
445 mm |
|
Weight |
14,5 kg |
|
Material |
Metal |
|
Electrical |
|
Power
input type |
Power Cable |
|
Power
source (Input) |
100 ~ 220V, 5A, 50/60 Hz |
|
Environmental |
|
Operation
temperature |
4 °C ~ 38 °C |
|
Storage
temperature |
-20 °C ~ 50 °C |
|
Humidty |
%0 ~ %90
(Non Condensing) |
|
Label |
|
Type |
Roll-feed, die-cut, continuous,
fan-fold, tags, ticket in
thermal paper or plain paper |
|
Width |
25,4 mm ~ 160 mm |
|
Thickness |
0.0635 ~ 0.254 mm |
|
Roll Inside diameter |
25,4 mm |
|
Roll Outside diameter |
203 mm (Maximum) |
|
Ribbon |
|
Type |
Wax, Wax/Resin and Resin |
|
Ink
side |
Inside /
Outside |
|
Width |
25,4 mm ~ 160 mm |
|
Length |
300 Meter (Max.) |
|
Roll Inside diameter |
25,4 mm |
|
Roll Outside diameter |
63 mm (Max.) |
|
Software |
|
Windows
drivers |
Windows 2000/XP/2003/VISTA/Windows
7 |
|
Label
Design programs |
Bartender UltraLite (Free) |
|
Utility programs |
Printer Utility and Font Utility |
|
Supported
barcode printing language |
PPLA |
|
Supported graphics formats |
PCX, BMP, IMG and HEX
formats |
|
Supported
Barcode Types |
|
1D |
Code39, Code93, Code128/subset A, B and C, Codabar,Interleaved 2 of 5, UPC A/E/2 and 5 add-on, EAN 13/8, UCC/EAN-128, UCC/EAN 128 random weight, Postnet, Plessey, HIBC, Telepen, FIM |
|
2D |
MaxiCode, PDF-417, Data Matrix(ECC 200 only) |
|
Accessories |
|
Optional Items |
Cutter |
|
RTC Card |
|
Dispencer Kit |
|
Media
Stacker |
|
2
MB Asian Font Card (For
Traditional Chinese, Simplified
Chinese, Korean and Japanese
Language) |
|
ArgoKee keyboard |
