● Direct Thermal And Thermal Printing
● 203 DPI Printing Resolution
● Max. 108 mm Printing Width
● Max. 2540 mm Printing Length
● Max. 178 mm / Sec Printing Speed
● 32 MB DRAM and 16 MB Flash ROM
● PPLA, PPLB and PPLZ Support
● Ribbon wound ink-side out or ink-side in available
● Printing noise improved
● RS-232C, USB and Ethernet Port
| Operational | |
| Printing method | Direct thermal and thermal transfer |
| Printing resolution | 203 DPI (8 dots/mm) |
| Printing speed (Maximum) | 178 mm/sec |
| Printing length | 13 mm ~ 2540 mm |
| Printing width | 25 mm ~ 108 mm |
| Memory | 32 MB DRAM and 16 MB Flash ROM |
| Proccessor | 32 Bit RISC proccessor |
| Operation interface | 1 button (Feed) and 2 LED (Power and Ready) |
| Communication interface | RS-232, USB, USB Host and Ethernet Port |
| Sensor | Reflective media sensor (Movable) |
| Transmissive media sensor (Fixed and Center) | |
| Print directions | 0, 90, 180, 270 degree |
| Agency listing | CE, FCC, cTUVus, CCC, RoHS |
| Physical | |
| Width | 209 mm |
| Height | 179,2 mm |
| Length (Depth) | 266 mm |
| Weight | 2,2 kg |
| Material | ABS Plastic |
| Electrical | |
| Power input type | External adaptor |
| Power source (Input) | 100V~240V±10%, 1.8A, 50~60Hz |
| Power source (Output) | 24VDC, 2.4A, 60 W Max. |
| Environmental | |
| Operation temperature | 5 °C ~ 40 °C |
| Storage temperature | -20 °C ~ 50 °C |
| Humidty | %25 ~ %85 (Non Condensing) |
| Label | |
| Type | Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper |
| Width | 25,4 mm ~ 118 mm |
| Thickness | 0,06 ~ 0,2 mm |
| Roll Inside diameter | Standart: 12,7 mm |
| Opsiyonel: 25,4 mm ~ 38 mm | |
| Roll Outside diameter | 115 mm (With 12,7 mm Core Diameter) |
| 127 mm (With 25,4 mm and 38 mm Core Diameter) | |
| 203 mm (With External Label Holder) | |
| Ribbon | |
| Type | Wax, Wax/Resin and Resin |
| Ink side | Outside |
| Width | 25,4 mm ~ 110 |
| Length | 110 Meter (Maximum) |
| Roll Inside diameter | 12,7 mm |
| Roll Outside diameter | 37 mm (Maximum) |
| Software | |
| Windows drivers | Windows XP / Vista / 7 / 8 / 8.1, Windows Server 2003 / 2008 / 2012 |
| Label Design programs | Bartender UltraLite (Free) |
| Utility programs | Printer Utility and Font Utility |
| Supported barcode printing language | PPLA, PPLB and PPLZ |
| Supported graphics formats |
PPLA:
PCX, BMP, IMG and HEX PPLB: PCX, BMP, GDI and Binary Raster PPLZ: GRF, Hex and GDI |
| Supported Barcode Types | |
| 1D |
PPLA: Code 39
(standard/with checksum digit),
Code 93 Interleaved 2of 5
(standard/with checksum
digit/with human readable check
digit), EAN-8, EAN-13,UPC-A,
UPC-E, Postnet, Codabar, Code
128 subset A/B/C, UCC/EAN-128,
UCC/EAN-128 K-MART, UCC/EAN-128
, Random Weight, Plessey, HBIC,
Telepen, FIM, UPC2, UPC5, GS1
Data Bar |
| 2D | PPLA/PPLB/PPLZ: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, Composite codes |
| Accessories | |
| Optional Items | FUll Cutter |
| Partial Cutter | |
| Peeler | |
| External Media Stand | |
| RTC | |
| Turkish | ||
| Data Sheets |
 |
|
| Users Manual |
|
|
| İngilizce | ||
| Data Sheets |
|
|
| Users Manual |
|
|
| Seagull Windows Driver | Windows XP, Vista, 7, Server 2003, Server 2008, Server 2008R2 (32 Bit & 64 Bit) |
|
| Bartender UltraLite | Label Design and Printing Software |
|
| Printer Utility | Printer Configuration Software |
|
| Font Utility | Font Create / Download Software |
|
| S.D.K | Software Developement Kit |
|
