Reading Performance |
|
Image Sensor |
Wide VGA (640 x 480 Piksel) |
|
Light source |
Aiming: 1 Blue LED (468 nm) |
|
Illumination: White LED (624 nm) |
|
Motion
Tolerance |
30 IPS |
|
Print Contrast
(Minimum) |
15% |
|
Reading Angle |
Pitch: ±65°; Roll (Tilt): ±360°, Skew (Yaw): ±65° |
|
Indicators (LED) |
Beeper (Adjustable Tone and Volume); Datalogic ‘Green Spot’ Good Read Feedback; Good Read LED |
|
Resolution |
1D Linear: 0.077 mm (3 mil) |
|
PDF417: 0.127 mm (5 mil) |
|
Data Matrix: 0.152 mm (6 mil) |
|
Qr Code: 0.17 mm (6.7 mil) |
|
Interface |
|
|
Interfaces |
QW2520: USB (Type-C) |
|
Physical |
|
|
Height |
148 mm |
|
Depth |
126 mm |
|
Width |
68 mm |
|
Weight |
145 gr |
|
Color |
Black |
|
Electrical |
|
|
Current |
Operating (Typical): 450 mA @5VDC |
|
Standby Mode: 90 mA @5VDC |
|
Input Voltage |
5 VDC |
|
Environmental |
|
|
Ambient Light |
100.000 Lux (Max.) |
|
Operation temperature |
0°C ~ 50°C |
|
Storage temperature |
-40°C ~ 70°C |
|
Humidty |
%0 ~ %95 (Non Condensing) |
|
Drop Durability |
1,5 meter |
|
IP Standard |
IP52 |
|
ESD Protection (Air
Discharge) |
16 kV |
|
Scanning Capability |
|
|
1D Linear Barcodes |
Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes |
|
2D Codes |
Aztec Code; Aztec Mesas; Data Matrix; MaxiCode; QR Code, Micro QR Code; China Han Xin Code |
|
Postal Codes |
Australian Post; British Post; Canadian Post; China Post; Japanese Post; IMB; KIX Post; Planet Code; Postnet; Royal Mail Code (RM4SCC) |
|
Stacked Codes |
EAN/JAN Composites; GS1 DataBar Composites;GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional;MacroPDF; MicroPDF417; PDF417; UPC A/E Composites |
|
Scanning Distances |
|
|
Scanning Distances |
Code 39: (5 mils) 5 mm ~ 230 mm |
|
Code 39: (10 mils) 5 mm ~ 370 mm |
|
EAN/UPC-A: (13 mils) 10 mm ~ 400 mm |
|
PDF417: (6,7 mils) 5 mm ~ 135 mm |
|
DataMatrix: (10 mils) 10 mm ~ 155 mm |
|
QrCode: (20 mils) 10 mm ~ 330 mm |
|
Safety and Regulatory |
|
|
Agency Approvals |
The product meets necessary
safety and regulatory approvals
for its intended use. |
|
Environmental Compliance |
Complies to China end EU RoHS |
|
LED Classification |
Illuminator Exempt group, Aiming Risk Group 1 according to IEC 62471 |
|
Utilities |
|
|
DATALOGIC ALADDIN™ |
Datalogic Aladdin configuration program is available for download at no charge |
|
OPOS / JAVAPOS |
JavaPOS Utilities are available for download at no
charge.
OPOS Utilities are available for download at no
charge |
