Decoding Capability |
|
|
1D Linear Barcodes |
GS1 DataBar™ linear codes, UPC/EAN, UPC/EAN P2/P5 add ons, UPC/EAN Coupons, ISBN, Code 128,EAN 128, Code 39, Code 39 Full ASCII, Code 39 CIP, Code 32, Codabar, Interleaved 2 of 5, IATA, Industrial 2 of 5, Standard 2 of 5, Code 11, MSI, Plessey, Code 93, Follet 2/5, Code 4, Code 5, Datalogic 2 of 5,Codablock F |
|
Electrical |
|
|
Input Voltage |
4,5 - 30 VDC |
|
Current |
Operating: 440 mA @ 4.5 V; 380 mA @ 5 V; 75 mA @30 V |
|
Environmental |
|
|
Light Levels |
Immune to light exposure in offices/facilities and direct exposure to sunlight |
|
Drop Durability |
Withstands 50 drops from 2.0 m / 6.6 ft to concrete |
|
ESD Protection (Air
Discharge) |
20
kV |
|
Humidty |
0 - 95% (Non Condensing) |
|
Operation temperature |
-20°C ~ 50°C |
|
Storage temperature |
-40 °C ~ 50 °C |
|
IP Standard |
IP65 |
|
Interfaces |
|
Supported Interfaces |
Keyboard Wedge, RS-232, USB |
|
Physical |
|
|
Dimensions |
21.2 x 11.0 x 7.4 cm / 8.4 x 4.3 x 2.9 in |
|
Weight |
340 gr |
|
Color |
Yellow/Black |
|
Reading
Performance |
|
Light Source |
Green LED |
|
Print Contrast Ratio (Min.) |
15% |
|
Read Rate |
35±5
Scan / Sec |
|
Reading Angle |
Pitch: +/- 65°; Roll (Tilt): 360°; Skew (Yaw): +/- 65° |
|
Reading Indicators |
Beeper; Datalogic Three Green Lights (3GL™) Good Read Feedback: Datalogic ‘Green Spot’ on the Code,Dual Good Read LEDs |
|
Resolution (Max.) |
2.5 mils |
|
Scanning Distances |
|
|
Code 39 |
5 mil: 30 mm ~ 320 mm |
|
7,5 mil: 20 mm ~ 480 mm |
|
10 mil: 20 mm ~ 660 mm |
|
20 mil: 30 mm ~ 1100 mm |
|
40 mil: 30 mm ~ 230 mm |
|
EAN-13 |
20 mm ~ 610 mm |
|
Safety and Regulatory |
|
|
Agency Approvals |
The product meets necessary
safety and regulatory approvals
for its intended use. The Quick
Reference Guide for this product
can be referred to for a
complete list of certifications. |
|
Environmental Compliance |
Complies to China RoHS; Complies to EU RoHS |
|
Laser Classification |
Product compliant according to IEC 62471 |
|
Utilities |
|
|
Datalogic Aladdin™ |
Datalogic Aladdin configuration program is available for download at no charge |
|
OPOS JavaPOS |
JavaPOS and OPOS Utilities are available for download at no charge |
