● Android 11 operation systems
● Supported Google Mobile Services
● Octa Core 2,0 Ghz proccessor
● 4 GB RAM, 64 GB ROM
● 4 Inch (800 x 480 pixel) capacitive touch screen
● Wifi, Bluetooth and NFC technology
● IP65 Protection Class
| System | ||
| Micro Processor | Octa Core 2,0 Ghz 64 Bit ARM Proccessor | |
| Memory | 4 GB RAM, 64 GB ROM | |
| Operation System | Android 11 | |
| GMS Support | Available (GMS=Google Mobile Service) | |
| Camera | Front: 13 megapixels (Auto focus, with LED flashlight) | |
| Rear: 5 megapixels (Fixed focus) | ||
| Notification | Vibrator, Multi Color LED and Speaker | |
| Keypad | 30 Pcs (Including side keys) | |
| Expansion | MicroSD card slot (Max. 128 GB) | |
| Certifications | CE-RED, BIS, RoHS2.0, REACH, SOTI, UN38.3, IEC62471 | |
| Display | ||
| Display Type | WVGA | |
| Touch Screen Type | Capacitive, Corning gorilla glass | |
| Dimension | 4" (Inch) | |
| Resolutioin | 800 x 480 Pixel | |
| Barcode Scanner | ||
| Type | 2D Area Imager | |
| Optical System | 1280 x 960 CMOS (Mega Pixel) | |
| Illumination | 625 ± 10 nm White LED | |
| Aiming | Laser Diode | |
| Scan Mode | Trigger Mode, Sense Mode | |
| Scan Rate | 60 Frame Per Second | |
| Supported Barcode Types | 1D | All Major 1D Symbologies |
| 2D | All Major 2D Symbologies | |
| Communications | ||
| USB | USB Type-C | |
| Wifi | built-in 802.11 a/b/g/n/ac, compatible with 11 d/h/i/k/r/v/w, support 2.4G and 5G dual frequency | |
| Bluetooth | Dual Mode Bluetooth 5.0 + LE (Backward compatible) | |
| WWAN | 4G: TD-LTE (B38, B39, B40, B41); FDD-LTE (B1, B3, B7, B20) | |
| SIM Slot: Nano+Nano or Nano+TF | ||
| GPS | GPS (AGPS), GLONASS | |
| RFID | Frequency: 13,56 Mhz | |
| Supported Tags: ISO14443A/B, MIFARE, Felica, NFC Forum Tags, ISO15693 | ||
| Electrical | ||
| Power Supply (Input) | AC100 ~ 240V, 50 ~ 60Hz | |
| Power Supply (Output) | DC5V, 2A | |
| Main Battery | 3.7V, 3800 mAh (Removable) | |
| Expected Charge Time | 4,5 ~ 5 Hours (Via AC Adapter) | |
| Working time | Max: 10 Hours | |
| Physical | ||
| Dimensions | Width | 73 mm |
| Length | 166 mm | |
| Thickness | 26 mm | |
| Weight | 330g (including battery) | |
| Enviromental | ||
| Operating temperature | -20°C to 55°C | |
| Storage temperature | -30°C to 70°C | |
| Humidty | %5 ~ %95 (Non Condensing) | |
| ESD | ±15 kV (Air Discharge), ±8 kV (Direct Discharge) | |
| Drop | 1,5 meter | |
| Sealing | IP65 (Optional IP67) | |
| Accessories | ||
| Standart | USB Cable, Battery, Hand strap, Plastic cover | |
| Optional | AC adapter, cable, charging cradle, hand strap, 4-slot charger | |
