● Corded 2D Imager Scanner
● Light weight, ergonomic design
● 640 X 480 Pixel CMOS Sensor
● 1D:(4 mil) Resolution
● 40 ~ 220 mm scanning distance
● Scanning From Display
● USB Interface
| Performans | |
| Image Sensor | CMOS |
| Resolution | 640 X 480 Pixel |
| Light Source | Marking: Red LED, Lighting: White LED |
| Resolution | 1D= Min: 4 Mil |
| Scanning Distances | 40 - 220 mm (0,33 mm pcs 0.9, EAN13) |
| Rotational Sensitivity | Rotation: 360° tilt: ±50° deflection: ±50° |
| Field of view angle | Horizontal 36° , Vertical 23° |
| Print Contrast (Minimum) | Min: %15 |
| Indicators (LED) | Beeper and LED |
| Scanning Mod | Manual and Continous |
| Supported Interfaces | USB, RS232 and USB-VCP |
| Physical | |
| Height | 102 mm |
| Length | 175 mm |
| Width | 73 mm |
| Weight | 238 gr |
| Case Material | ABS + PC |
| Color | Black |
| Cable | Standart 2 Meter Straight |
| Electrical | |
| Voltage | DC 5V |
| Current | Operation Mode: 230 mA |
| Stand by Mode: 150 mA | |
| Environmental | |
| Operation temperature | -10°C ~ 55°C |
| Storage temperature | -20°C ~ 60°C |
| Humidty | %5 ~ %95 (Non Condensing) |
| Light Levels | 0 ~ 100.000 Lux |
| IP Standart | IP54 |
| Drop Test | 1,5 Meter |
| Certification | CE |
| Decoding Capability | |
| 1D Barcodes | UPC-A, UPC-E, EAN-8, EAN-13, Code39, Codabar, Code128, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 93, UCC/EAN 128, Code 11, MSI, UK/Plessey, ISBN/ISSN, GS1 Databar Expanded, GS1 Databar, GS1 Databar Limited |
| 2D Barcodes | QRCode, PDF417, Datamatrix |
