● 2D Imager Barcode Scanner
● Wifi and Bluetooth Communication (With Setting)
● Data Transmission Range: Wifi: Max. 100 meter, Bluetooth: Max. 10 meter
● Min. 4 mil Resolution
● 65 ~ 270 mm Scanning Distance
● Reading from LCD Display
● Compatible Windows, Android and iOS Devices
| Operational | |
| Light Source | Illumination: White LED |
| Aiming: Red LED | |
| CPU | 32 Bit ARM |
| Image Sensor | CMOS |
| Image Size | 640 x 480 Pixel |
| Supported Barcode Types | 1D (Linear) ve 2D (Imager) |
| Minumum Bar Width | 4 mil |
| Scanning Distances | 65 - 270 mm (13 mil PCS %90) |
| Print Contrast | >%25) |
| Scensitivity | Roll:360° Skew:±65°, Pitch:±60° |
| Scan Speed | 30 fps/s |
| Scan Mode | Manual & Automatic |
| Memory capacity | 16 MB (Max. 2 Milion EAN 13 Barcodes) |
| Indicator | Ring LED and Buzzer |
| Interfaces | USB、USB-VCP |
| Communication | |
| Technology | Wifi And Bluetooth (With Settings) |
| Communication Mode | Wifi: 2,4 Ghz |
| Bluetooth: 4.0 | |
| Communication Distance | Wifi: Max. 100 meter (At open places) |
| Bluetooth: Max. 10 meter (At open places) | |
| Decoding Capability | |
| 1D | UPC-A, UPC-E, EAN-8, EAN-13, Code 128, Code 39, Code 32, Codabar(NW-7), Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Standard 2 of 5(IATA), Code 11, MSI Plessey |
| 2D | QR Code, Micro QR Code, Data Matrix, PDF417 |
| Electrical | |
| Battery Type | Litium Ion |
| Battery Capacity | 1500 mAh |
| Operating Current | Working mode: 185 mA |
| Stand by Mode: <85mA | |
| Battery Life | Stand By: Max. 6 Days |
| Charging Method | With USB Type-C Cable Charge |
| Input Voltage | DC 5V |
| Charging Time |
Max. 4 Hours |
| Physical | |
| Scanner | Length: 110 mm |
| Width: 40 mm | |
| Height: 18,6 mm | |
| Receiver | Length: 18 mm |
| Width: 14 mm | |
| Height: 6 mm | |
| Weight | Scanner: 66 gram |
| Material | Abs + TPU |
| Environmental | |
| Drop Durability | 1,5 meter |
| Illumination | 0 ~ 100.000 Lux (Sunlight) |
| Operation temperature | -10°C ~ 50°C |
| Storage temperature | -20°C ~ 70°C |
| Humidty | %5 ~ %95 (Non Condensing) |
