● Windows CE.NET 5.0 operation systems
● Intel PXA-270 (520 Mhz) proccessor
● 64 MB RAM, 64 MB ROM
● 5.7” TFT VGA color touch panel
● A PoE Enabled networking device
● Equipped with stereo speakers for multimedia purpose
● Free Price Checker Software
| System | |
| CPU | Intel PXA 270 (520 Mhz) proccessor |
| RAM | 64 MB |
| Flash ROM | 64 MB |
| Operation Systems | Microsoft Windows CE .NET 5.0 Professional |
| Display | |
| Type | Color transmissive TFT LCD with touch panel and LED back light |
| Size | 5,7" |
| Resolution | 480 x 640 pixel |
| Physical | |
| Length | 245,1 mm |
| Width | 204,0 mm |
| Height | 117,6 mm |
| Weight | 1.400 gr |
| Keys | 5 Keys: HOME, ESC, Up/Right/Down/Left, ENT (Enter), FN (Function) |
| Alert | Speaker and LED |
| LED | Blue, Green and Red |
| Drop test | - |
| Sealed standard | - |
| EMC | CE & FCC Part 15B |
| Expansion Slot | |
| C/F Card Slot | Internal one compact flash Type II card slot (for data storage only) |
| SD I/O Card Slot | One SD I/O card slot for removable memory cards up to 2GB |
| Interface | |
| Ethernet | 10/100 Mbps Ethernet (Supports PoE, IEEE 802.3af compliant) |
| USB |
USB version 1.1 Host for
external device (back) USB version 1.1 Client for external device (side) |
| RS-232C | Programmable up to 115,200 bps |
| WLAN | IEEE 802.11 b/g |
| Scanner | |
| Type | Zebex A-50 M omni directional 1D laser scanner |
| Supported barcode | UPC/EAN/JAN, ISBN, ISSN, Code 39 (with Full ASCII), Codabar (NW7), Code 128, EAN 128, Code 93, Interleaved 2 Of 5, Addendum 2 or 5, Iata Code, MSI/Plessey, China Postal Code, Code 32 (Italian Pharmacode), Industrial 2 Of 5, Standart 2 Of 5, |
| Power | |
| AC Adaptor | 9V-DC, 2A, 110V/220V input AC auto switching |
| Environmental | |
| Operation temperature | 0 °C ~ 50 °C |
| Storage temperature | -10 °C ~ 60 °C |
| Operation Humidty | %10 ~ %70 (Non Condensing) |
| Storage Humidty | %5 ~ %70 (Non Condensing) |
| Software | |
| Software | Visual Studio. NET |
| Zebex Z-7010 SDK | |
| Accessories | |
| Accessories | Charging & Communication Cradle |
| Vehicle charging cable | |
| Turkish | ||
| Data Sheets |
 |
|
| ActiveSync 4.5 | Synchronization software (For Windows XP) |
|
| Mobile Device Center (32 Bit) | Synchronization software (For Windows Vista / 7 / 8 / 8.1 / 10) |
|
| Mobile Device Center (64 Bit) | Synchronization software (For Windows Vista / 7 / 8 / 8.1 / 10) |
|
| English | ||
| Data Sheets |
|
|
| User Manual |
|
|
| ActiveSync 4.5 | Synchronization software (For Windows XP) |
|
| Mobile Device Center (32 Bit) | Synchronization software (For Windows Vista / 7 / 8 / 8.1 / 10) |
|
| Mobile Device Center (64 Bit) | Synchronization software (For Windows Vista / 7 / 8 / 8.1 / 10) |
|
| PowerToys | Remote Managment Software |
|
