Operational |
|
Light source |
650 nm (±10) visible laser diode (VLD) |
|
Scan Pattern |
Single Line |
|
Scan Angle |
46° (Horizontal) |
|
Depth of field |
0 - 228 mm |
|
Scan Rate |
72 scans/sec |
|
Minimum Bar Width |
0.1 mm (4 mil) |
|
Indicators (LED) |
Green and Red LED |
|
Beeper Operation |
Programmable tone & beep time |
|
System Interfaces |
USB |
|
Physical |
|
|
Height |
153 mm |
|
Depth |
110 mm |
|
Width |
70
mm |
|
Weight |
120 gr (Without Cables) |
|
Cables |
Standard 2 meter straight |
|
Material |
Abs
Plastic |
|
Electrical |
|
|
Input Voltage |
5VDC ± 0.25V |
|
Operating Current |
Stand By Mod : 675 mW (125
mA@5V) |
|
Operation Mod: 1000 mW (200
mA@5V) |
|
Laser Level |
Class 1;
IEC60825-1, EN60825-1 |
|
Agency Approval |
CE , FCC
and BSMI |
|
Environmental |
|
|
Operation temperature |
0°C ~ 40°C |
|
Storage temperature |
-40 °C ~ 60 °C |
|
Humidty |
%5 ~ %95 (Non Condensing) |
|
Light Levels |
Max
4.842 Lux (fluorescence) |
|
Drop Durability |
1 meter |
|
Decode
Capabilities |
|
|
Barcode Types |
Codabar, Code 3 of 9 including
PARAF, Interleaved 2 of 5,
Straight 2 of 5 Industrial,
Matrix 2 of 5, Code 11, Code 93,
Code 128, UPC, EAN/JAN, China
Postal Code, GS1 DataBar. 2005
Sunrise/GTIN compliant |
