● 1D Omnidirectional laser barcode scanner
● 20 Number of scan Line
● 1500 Scan per second
● 0,127 mm (5 mil) resolution
● 0 ~ 200 mm scanning distance
● RS-232C, PS/2, USB and Virtual COM Interface
| Operational | |
| Light source | 650 nm (±10) visible laser diode (VLD) |
| Scan Pattern | 5 directions of scan field |
| Number of Scan line | 20 |
| Depth of field | 0 - 200 mm |
| Scan Rate | 1500 scans/sec |
| Minimum Bar Width | 0,127 mm (5 mil) |
| Print Contrast | %30 |
| Indicators (LED) | LED and Beeper |
| System Interfaces | PS/2, RS-232C and USB |
| Physical | |
| Width | 152 mm |
| Height | 152 mm |
| Depth | 78 mm |
| Weight | 610 Gr |
| Cables | Standard 2 meter straight |
| Material | Abs Plastic |
| Color | Black |
| Electrical | |
| Input Voltage | +5V DC |
| Power | 1.0 Watt |
| Static Current | 250 mA |
| Environmental | |
| Operation temperature | 0°C ~ 45°C |
| Storage temperature | -20 °C ~ 60 °C |
| Humidty | %5 ~ %85 (Non Condensing) |
| Ortam Işık Seviyesi | Max. 5.000 Lux |
| Drop Durability | 1,5 Meter |
| Decode Capabilities | |
| Barcode Types | UPC/EAN/JAN, UPC/EAN with Supplementary, JAN 8 & JAN 13, ISBN/ISSN, EAN, Code 39, Code 39 with full ASCII, Code 93, Code 128, Codabar (NM7), Trioptic Code 39, MSI/Plessey, GS1 Code, Interleaved 2 of 5, Addendum 2 of 5, IATA Code, China Postal Code, Code 32, Industrial 2 of 5, Standart 2 of 5, Discrete 2 of 5, Matrix 2 of 5, Code 11, UPC/EAN RSS, RSS Variants |
