● Android 11 operation systems
● Quad Core 2,0 Ghz proccessor
● 3 GB RAM, 32 GB ROM
● 4 Inch (800 x 480 pixel) capacitive touch screen
● Wifi, Bluetooth, 4G (Data) and NFC technology
● 1,2 mt (4 ft) drop resistance
● IP65 Protection Class
● 8 MP Autofocus Camera with LED Flash
| System | ||
| Micro Processor | Quad Core 2,0 Ghz 64 Bit ARM Proccessor | |
| Memory | 3 GB RAM, 32 GB ROM | |
| Operation System | Android 11 | |
| GMS Support | Available (GMS=Google Mobile Service) | |
| Camera | 8 megapixels, auto focus, with LED flashlight | |
| Notification | Vibrator, Multi Color LED and Speaker | |
| Keypad | 30 Pcs (Including side keys) | |
| Expansion | MicroSD card slot (Max. 128 GB) | |
| Certifications | FCCID, RoHS, IEC62471, EN60950 | |
| Display | ||
| Display Type | WVGA | |
| Touch Screen Type | Capacitive | |
| Dimension | 4" (Inch) | |
| Resolutioin | 800 x 480 Pixel | |
| Barcode Scanner | ||
| Type | 2D Area Imager | |
| Optical System | 1280 x 960 CMOS (Mega Pixel) | |
| Illumination | 625 ± 10 nm White LED | |
| Aiming | Laser Diode | |
| Scan Mode | Trigger Mode, Sense Mode | |
| Scan Rate | 60 Frame Per Second | |
| Supported Barcode Types | 1D | All Major 1D Symbologies |
| 2D | All Major 2D Symbologies | |
| Communications | ||
| USB | Micro USB | |
| Wifi | IEEE 802.11 b/g/n (2.4GHz and 5GHz) | |
| Bluetooth | Bluetooth 5.0 LE (Backward compatible) | |
| WWAN | 4G: TD-LTE (B38, B39, B40, B41); FDD-LTE (B1, B3, B7, B20) | |
| SIM Slot: Mini SIM | ||
| GSM | Not Supported | |
| GPS | GPS (AGPS), GLONASS | |
| RFID | Frequency: 13,56 Mhz | |
| Supported Tags: ISO14443A/B, MIFARE, Felica, NFC Forum Tags, ISO15693 | ||
| Electrical | ||
| Power Supply (Input) | AC100 ~ 240V, 50 ~ 60Hz | |
| Power Supply (Output) | DC5V, 2A | |
| Main Battery | 3.7V, 3800 mAh (Removable) | |
| Expected Charge Time | 4,5 ~ 5 Hours (Via AC Adapter) | |
| Working time | Max: 10 Hours | |
| Physical | ||
| Dimensions | Width | 73 mm |
| Length | 166 mm | |
| Thickness | 26 mm | |
| Weight | 330g (including battery) | |
| Enviromental | ||
| Operating temperature | -20°C to 50°C | |
| Storage temperature | -30°C to 70°C | |
| Humidty | %5 ~ %95 (Non Condensing) | |
| ESD | ±15 kV (Air Discharge), ±8 kV (Direct Discharge) | |
| Drop | 1,2 meter | |
| Sealing | IP65 | |
| Accessories | ||
|
Accessories (Optional Items) |
USB Cable | |
| Charging Cradle | ||
| Battery | ||
| AC Adapter | ||
| Hand Strap | ||
| Pistol Grip | ||
| 4 Slot Charger | ||
| Turkish | ||
| Data Sheets |
 |
|
| English | ||
| Data Sheets |
|
|
| User Manual |
|
|
